Flat Knitting Transfer Needles

•  Transfer needles are specialized knitting elements designed to relocate loops from one needle bed to another during the flat knitting process. This function is essential for producing shaped garments, cables, intarsia, and complex stitch patterns without manual intervention. The working principle involves a precisely engineered transfer spring or movable hook that opens to receive a loop, then closes to hold it securely as the loop is transferred across beds. The receiving needle catches the loop, completing the handover. Manufactured from high-grade steel with advanced heat treatment, our transfer needles ensure smooth, reliable transfer action, minimizing dropped stitches and production downtime. Available in various gauges to match all major machine brands including Stoll, Shima Seiki, Cixing, Universal,  Steiger ,Kauoheng, jumberca, Guosheng and Protti and so on. Here you will find most of the transfer knitting needles for computerized flat knitting machine, also including jacks, selectors for below most popular brand of flat bed knitting machines.

• Precision Transfer Spring – Engineered for consistent opening and closing action, ensuring secure loop handover every cycle.
• Advanced Heat Treatment – Vacuum hardening and tempering deliver optimal hardness (≥ 60 HRC) with superior toughness.
• Mirror-Finish Polishing – Our advanced polishing system delivers a mirror-like finish on the needle shank, while ensuring that the transfer spring and hook remain completely undamaged throughout the process – reducing friction and yarn abrasion.
• Dimensional Precision – Manufactured to tight tolerances (±0.01mm) for perfect compatibility with machine cams and needle beds.

              Specification:    Description

• Needle Type:  Transfer needle (movable hook / transfer spring design)
• Gauge Range: 1.5G – 18G (custom gauges available upon request)
• Material: High-grade steel.
• Hardness: 60 – 64 HRC
• Surface Finish: Mirror-polished shank; precision-ground hook and spring
• Applicable Machines: Stoll, Shima Seiki, Protti, and other major flat knitting machine brands
• Applications:  Shaped garments, collars, cuffs, cables, intarsia, jacquard, and 3D knitwea

              Benefit:                                Value to Customer

• Reliable Loop Transfer: Precision spring mechanism ensures zero dropped stitches during transfer
• Extended Service Life:High-grade material + heat treatment delivers exceptional durability
• Reduced Yarn Breakage: Mirror-polished surfaces minimize friction and yarn stress
• High-Speed Compatibility: Maintains stability at machine's rated maximum speed
• Low Maintenance: Consistent geometry reduces wear on machine cams and beds

  To assist customers in selecting the right transfer needle for their specific application:

• Consideration:      Recommendation
• Machine Brand & Model:Provide your machine type and model for precise matching
• Gauge: Match to your machine's gauge; lower gauge (1.5G–10G) for coarse yarns, higher gauge (12G–18G) for finer yarns
• Transfer Type: Standard transfer (basic loop relocation) or specialized transfer (cables / multi-color patterns)
• Yarn Type & Count: Coarse/spun yarns → larger hooks; fine/smooth yarns → finer precision hooks

Transfer needles operate on a simple yet precise mechanical principle:

• Loop Preparation – The transfer needle approaches the loop to be transferred, with its hook in the open position.
• Loop Engagement – The hook receives the loop from the original needle, while the transfer spring opens to allow loop entry.
• Loop Securing – The transfer spring closes, locking the loop securely onto the hook.
• Lateral Movement – The needle bed racks or the carriage moves to align the transfer needle with the receiving needle on the opposite bed.
• Loop Handover – The receiving needle extends, catches the loop from the transfer needle's hook, and the transfer spring opens to release the loop.
• Completion – The receiving needle retracts with the loop now secured, completing the transfer cycle.

This mechanism enables complex stitch structures, garment shaping, and seamless knitting without manual rehanging of loops.

• Incoming Material Inspection – Certified alloy steel with full traceability and mill test reports
• In-Process Monitoring – Dimensional and hardness checks at each production stage
• Final Testing – 100% visual inspection and functional sampling on test machines
• Certifications – ISO 9001:2015 compliant manufacturing; CE marking available upon request

              Service:        Details

• Lead Time: Standard: 5–25 working days (depending on gauge and quantity)
• MOQ: Flexible – samples and small-batch orders welcome
• Warranty: Against manufacturing defects (specific terms available)
• Technical Support: Remote or email consultation for selection, installation, and troubleshooting
• OEM / ODM: Customized specifications and branding available for volume orders
• Sample Service: Trial samples available for qualification testing
